  • Dual Channel 4 to 20 mA Current Loop Simulator TROUBLESHOOTING TOOL
  • Troubleshooter Dual Channel 4 to 20 mA Current Loop Simulator TROUBLESHOOTING TOOL
  • Troubleshooter Dual Channel 4 to 20 mA Current Loop Simulator TROUBLESHOOTING TOOL

    Dual Channel 4 to 20 mA Current Loop Simulator TROUBLESHOOTING TOOL

    Troubleshooter

    MSRP:
    Now: $89.95
    (You save )
    (No reviews yet) Write a Review
    SKU:
    DCU-SIM
    Condition:
    New
    Availability:
    Ships the next business day (call if overnight needed)
    Weight:
    1.00 LBS
    Shipping:
    Calculated at Checkout
    Bulk Pricing:
    Buy in bulk and save

    Bulk discount rates

    ×

    Below are the available bulk discount rates for each individual item when you purchase a certain amount

    • Buy 5 - 10 and get $2.00 off
    • Buy 11 - 20 and get $3.00 off
    • Buy 21 or above and get $4.00 off

    Adding to cart… category.add_cart_announcement
    Add to Wish List
    • Create New Wish List

    Share This Article

    • Overview
    • Reviews

    Product Description

    The Current Loop Simulator/Generator was developed to assist maintenance personnel and integrators in 4 to 20 mA analog input testing, troubleshooting and application development for a reasonable cost.

    You can also see our store for our Pro version that is self powered or the single channel

    There are many reasons that we have came up with this and our other integrator tools, some include...

    1. Small and light enough to fit in your tool pouch or laptop bag.
    2. Easy to use.. just wire it up and start troubleshooting your system and producing a usable signal.
    3. So many times you need to generate a signal, then go to the other end (PLC, Controller, etc) and watch that signal
    4. For the price you can not afford to do without one or two... under 50.00 (free shipping in the US)


    It simulates a 2-wire loop powered transmitter.

    Five fixed output settings are available: 4 mA, 8 mA, 12 mA, 16 mA or 20 mA. two channels



    A specific output selection made by connecting signal wire to one of the five output terminals

    Simulator can work with wide range of loads from 0 to 1000 Ohm, typical analog input impedance is 250 Ohm.
    Loads above 400 Ohm require 24V or higher loop power supply
    Output accuracy is ±1% of the full scale or ±0.20mA

    A typical 2-wire installation requires a loop power supply usually provided by an external 24VDC power supply
    Some sourcing Analog Input modules can provide loop power also.
    Follow the Analog Input Module specification for a power supply selection



    This DIN rail mountable version of our 4-20 mA current loop simulator includes two analog channels capable of simulating 4, 8, 12, 16, and 20 mA signals.



    • Power Supply 12-30V DC 24VDC typical
    • Current Output
      • Number of Channels 2 Isolated
      • Output Range 4mA to 20mA
      • Fixed Preset 4 , 8, 12, 16, 20 mA Output Selection Terminal
      • Output Accuracy ±1% of full scale( 0.2mA) at 25°C
    • Protection Reverse Polarity
    • Load Range 0-1000 Ohm 250 Ohm typical.  Loads over 500 Ohm require 24V or higher power supply.



    Made in the USA





    Notes:

    • Item(s) are shipped the next business day once payment is received and cleared.
    • We offer a 30day guarantee on all of our products. No risk, guaranteed if our item(s) fail please contact us to discuss refund or exchange (excluding S&H).  Our programming cables have a LIFETIME guarantee. If the item is factory sealed by the manufacture it must be returned still with the factory sealed package or no refund will be given





    Shipping: Monday-Friday (no shipping on Saturday or Sunday) Call if you need overnight shipping before you order

    • We ship the next business day
    • First Class USPS 3-7 days
    • Priority Mail USPS, 2-3 business days
    • UPS Overnight UPS 1 business day
    • UPS Ground 1-6 business days
    • International Express USPS Mail 5-14 days with tracking number (via EMS)
    • International UPS 1-5 Business days
